Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 393
Expansion cards and backup units
Figure 276: Installing the coprocessor card mounting bracket (Intel) (B)
Figure 277: Installing the GPGPU card mounting bracket (Nvidia) (B)
Ê Hook in the GPGPU / coprocessor card mounting bracket under the upper
rim of the side chassis wall as shown (1).
Ê Fold the lower edge of the mounting bracket toward the chassis wall as
shown (2).
for Intel
for Nvidia
