Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 397
Expansion cards and backup units
Figure 283: Securing the coprocessor card (Intel) (A)
Figure 284: Securing the GPGPU card (Nvidia) (A)
Ê Secure the GPGPU / coprocessor card to the upper rear edge of the chassis
with two M3 x 4.5 mm screws.
Ê While securing the card, slightly press the it towards the server rear.
Ê Secure all remaining slot brackets to the upper rear edge of the chassis with
one M3 x 4.5 mm screw each.
for Intel
for Nvidia
