Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 399
Expansion cards and backup units
Figure 287: Securing the coprocessor card (Intel) (C)
Figure 288: Securing the GPGPU card (Nvidia) (C)
Ê Secure the GPGPU / coprocessor card to the mounting bracket.
Intel cards Nvidia cards
Screw
M3 x 4 mm flat head screw
(part of the card kit)
M3 x 4.5 mm
(C26192-Y10-C67)
Screw torque 0.4 Nm 0.6 Nm
for Intel
for Nvidia
