Ê If applicable, power cabling of a second GPGPU / coprocessor card is
performed according to the primary card:
– For Intel Xeon Phi 5110P and Nvidia cards:
I For further information, please refer to cabling plan "Cabling of
standard GPGPU / coprocessor cards" on page 757.
– For Intel Xeon Phi 3120P / 31S1P / 7120P cards:
I In case of Xeon Phi 3120P / 31S1P / 7120P cards, the standard
HDD power cable T26139-Y3952-V601 is replaced by power
cable T26139-Y3952-V701.
For further information, please refer to cabling plan "Cabling of
high performance GPGPU / coprocessor cards" on page 758.
Cable Connector
1
T26139-Y3946-V701
8-pin connector
2 6-pin connector
Cable Connector
1 T26139-Y3946-V701 8-pin connector
2 T26139-Y3952-V701 6-pin connector P2
