Figure 305: Installing the system fan holder (B)
Ê Ensure that the fan connector on the fan holder is properly seated in the
dedicated opening in the GPGPU air duct (A, see close-up).
Ê Ensure that the system fan holder locks in place on both ends. To do so,
slightly move the GPGPU air duct to the left and right (see orange arrows)
until the V-shaped groove (B) fully rests in the dedicated opening in the
GPGPU air duct base.
