Fujitsu PRIMERGY RX350 S8

604 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Front panel and external connectors
Ê Disconnect the front LAN cable from the front LAN board.
Ê Remove the front LAN board from the chassis and set aside.
Figure 468: Disconnecting the front VGA cable
Ê If applicable, disconnect the front VGA cable from the system board (see
close-up).
Figure 469: Disconnecting front panel cables
