TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 637
Front panel and external connectors
Figure 501: Connecting front panel cables to the system board
Ê Connect the front panel cable and front VGA cable (if applicable to the
system board):
# Connector Cable
1 FRONTPANEL Front panel cable T26139-Y4015-V1
2 FRONT VGA Front VGA cable T26139-Y3994-V101
