Fujitsu PRIMERGY RX350 S8

700 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
System board and components
Ê Carefully close the load plate over the empty processor socket.
V CAUTION!
Be careful not to touch or bend the spring contacts on the processor
socket.
Figure 546: Attaching the protective socket cover (A)
Ê Carefully lower the protective socket cover onto the CPU socket in a vertical
motion until it snaps in place.
