iRMC-related status signals
Buttons
ID indicator
Global error
indicator
Description
blue flashing off
A remote connection has been
established. Local VGA output has
been disabled during the remote
session.
blue flashing orange flashing
An emergency flash of the iRMC
firmware is in progress.
Pos. Button Function
12 ID button
This button highlights the ID indicator on the front and
I/O panels for easy server identification.
13 Reset button
This button is used to reboot the system. It can be
pressed using the end of a paper clip.
V CAUTION!
Risk of data loss!
14 NMI button
This button is used to troubleshoot software and
device driver errors It can be pressed using the end of
a paper clip.
V CAUTION!
Use this button only if directed to do so by
qualified certified maintenance personnel!
15 On / Off button
This button is used to switch the server on or off.
I If the system is running an ACPI-compliant
operating system, the pressing the On / Off
button will performs a graceful shutdown.
