Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 99
Basic hardware procedures
Ê Ensure that the rack mounting brackets properly engage on both sides of the
chassis as shown in the close-up.
Figure 47: Installing the rack mounting frame (B)
Ê Ensure that the rack mounting brackets properly engage on both sides of the
chassis as shown.
Ê Secure the rack front cover to the chassis with two M3 x 4.5 mm screws on
either side.
