10. Remove the Output Tray Extender Sensor Cable.
Installation
1. Pass the Output Tray Extender Sensor Cable through the hole of the Front Cross Beam.
2. Pass the Output Tray Extender Sensor Cable through the hole of the left arch. Important: The blue color
should be facing you.
400 Chapter 5 Removal and installation ENWW
