9. Move the Carriage slightly to allow access to the Carriage Line Sensor, maintain a separation of 4 cm.
10. Remove one T-6 screw.
CAUTION: Make sure that the screw does not fall down into the Service Station.
11. Open the Carriage latch upwards to allow access to the Carriage Line Sensor.
404 Chapter 5 Removal and installation ENWW
