Keysight M8000 Series of BER Test Solutions User Guide 399
Setting up Patterns 7
3 Specify the number of symbols. Use the UP and DOWN button to
increase or decrease the number of symbols.
4 Specify the fill patterns.
5 Specify by using the ON/OFF toggle switch whether you want to use
Mask and Squelch (Electric Idle). In Squelch, the amplifier output is
zero.
6 After you have entered these parameters, click Create. The newly
created pattern will appear in the Pattern Editor pane.
7Click the Save icon to save the pattern. For more details, refer to
Saving Patterns on page 403.
Downloading Patterns
You can also download the pattern to either selected locations or on all
locations using the Download Pattern dialog. To do so, follow the given
steps:
1 Create a new pattern or open an existing pattern.
2Click on the Download button . If the pattern is not saved, a
message will appear to save the pattern before downloading.
3 Once saved, a Download Pattern dialog will appear. This dialog allows
you to download the selected pattern to either on all locations or on
the selected locations.
