OUT
Sets the trigger to the OUT token (OUT packet from host to
device).
IN
Sets the trigger to the IN token (IN packet from device to host).
SOF
Sets the trigger to the SOF token (start of frame marker and
frame number).
SETup
Sets the trigger to the SETUP token (address and endpoint
number in OUT transaction for setup to a control pipe).
*RST:
OUT
TRIGger<m>:USB:WADD
<AddressCheck>
Defines, whether the address check shall be activated or not.
Parameters:
<AddressCheck> ON | OFF
*RST: OFF
TRIGger<m>:USB:WEND <EndpointCheck>
Defines, whether the endpoint check shall be activated or not.
Parameters:
<EndpointCheck> ON | OFF
*RST: OFF
TRIGger<m>:USB:WETCheck <WithETCheck>
Defines, whether the Endpoint Type (ET) check shall be activated or not.
Parameters:
<WithETCheck> ON | OFF
*RST: OFF
TRIGger<m>:USB:WFRN <FrameNoChk>
Defines, whether the frame number check shall be activated or not.
Parameters:
<FrameNoChk> ON | OFF
*RST: OFF
TRIGger<m>:USB:WPAY <PayloadCheck>
Defines, whether the payload data check shall be activated or not.
