18 Appendix C: The RTC6 EtherBox
934
innovators for industry
95
RTC6 EtherBox: Installed RTC6 Ethernet Board. Upper side. Dimensions and connector positions. All dimensions in mm.
1
LASER SCANHEADs POWER
POWER
LED green LED yellow
ETHERNET
EXTENSION1 EXT2 MOF STEPPER SPI/ANA/UART
0
80
130
0
0
0
4x
O
RTC6 Ethernet
SCANLAB
Force DHCP
3
J0501
1
Air circulation direction
11.2
22.19
94.6
119.6
10.09 23.06 33.72 59.56 78.79
100.03
33.2
95.5
9.31 22.41 36.51 50.61 63.01
107.92
13.9 87.56
3.2
90.1
Legend
1. Force DHCP. . . . . . . . . . Jumper field Jumper field to ignore or not to ignore the saved static IP address.
Details like “Jumper Field ’Force DHCP’”, page 897.
