Scanlab RTC6 PCIe Board - Page 948

RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
948
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 12
As of scan system firmware  2001.
Only intelliWELD with varioSCAN
de
FCi.
Not: intelliWELD with varioSCAN FC:
Actual z axis position
Can only be read out from the channel of the scan head connector to which the
z axis is connected.
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #0
…
Bit #19
Unit with 16-bit protocol: In bits.
Value range with 16-bit protocol: [–32.768…+32.767].
Unit with 20-bit protocol: In bits.
Value range with 20-bit protocol: –524.288…+524.287.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 13 Reserved.
16-bit
protocol
20-bit
protocol
–
Bit #0
…
Bit #15
Bit #0
…
Bit #19
–
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 14 As of scan system firmware  2001.
Temperature of galvanometer scanner
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #0
…
Bit #19
Unit with 16-bit protocol: In 10
–1
°C.
Value range with 16-bit protocol: [–32.768…+32.767].
Unit with 20-bit protocol: In 160
–1
°C.
Value range with 20-bit protocol: –524.288…+524.287.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
