Scanlab RTC6 PCIe Board - Page 949

RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
949
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 15 As of scan system firmware  2001.
Servo board temperature
As of scan system firmware  5050.
Axis 1 (X-axis): Temperature of the servo board
Axis 2 (Y-axis): Temperature of the servo add-on board for evaluating the encoder
signals
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #0
…
Bit #19
Unit with 16-bit protocol: In 10
–1
°C.
Value range with 16-bit protocol: [–32.768…+32.767].
Unit with 20-bit protocol: In 160
–1
°C.
Value range with 20-bit protocol: –524.288…+524.287.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 16 As of scan system firmware  2001.
AGC voltage (position detector supply voltage)
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #0
…
Bit #19
Unit with 16-bit protocol: In 10
-2
V.
Value range with 16-bit protocol: [–32.768…+32.767].
Unit with 20-bit protocol: In 1600
–1
V.
Value range with 20-bit protocol: –524.288…+524.287.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
