RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
952
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 1B As of scan system firmware 2001.
AGC current (PD supply current)
16-bit
protocol
20-bit
protocol
Bit #0
Bit #15
Bit #0
Bit #19
Unit with 16-bit protocol: In mA.
Value range with 16-bit protocol: [–32.768…+32.767].
Unit with 20-bit protocol: In 16
–1
mA.
Value range with 20-bit protocol: –524.288…+524.287.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 1C As of scan system firmware 2066.
Hardware version of servo board
16-bit
protocol
20-bit
protocol
Bit #0
Bit #15
Bit #0
Bit #19
16-bit protocol:
2nnn = DCSB
5021 = ISB1
5031 = ISB2
6011 = microISB
20-bit protocol:
2nnn×16 = DCSB
5021×16 = ISB1
5031×16 = ISB2
6011×16 = microISB
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
