RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
953
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 1D
As of scan system firmware  2001.
Relevant for scan systems with galvanometer scanner heating.
Relative heating output of the corresponding galvanometer scanner heater
Not relevant for intellicube.
Not relevant for dynAXIS XS.
Not relevant for scan systems with water-cooled galvanometer scanners.
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #4
…
Bit #19
Unit with 16-bit protocol: In per mille.
Value range with 16-bit protocol: [0…1,000].
Unit with 20-bit protocol: In per mille.
Value range with 20-bit protocol: [0…1,000].
– Bit #0
…
Bit #3
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 1E As of scan system firmware  2001.
Serial number, lower 16 bits
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #4
…
Bit #19
Unit with 16-bit protocol: None.
Value range with 16-bit protocol: [0…65,535].
Unit with 20-bit protocol: None.
Value range with 20-bit protocol: [0…65,535].
– Bit #0
…
Bit #3
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
