RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
955
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 21 As of scan system firmware  2001.
SCANLAB article number, upper 16 bits
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #4
…
Bit #19
Unit with 16-bit protocol: None.
Value range with 16-bit protocol: [0…65,535].
Unit with 20-bit protocol: None.
Value range with 20-bit protocol: [0…65,535].
– Bit #0
…
Bit #3
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 22 As of scan system firmware  2001.
Version number of scan system firmware
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #4
…
Bit #19
Unit with 16-bit protocol: None.
Value range with 16-bit protocol: [0…65,535].
Unit with 20-bit protocol: None.
Value range with 20-bit protocol: [0…65,535].
– Bit #0
…
Bit #3
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
