20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
956
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 23 As of scan system firmware  2001.
Calibration angle
Mechanical scan angle (±) for 96% of the maximum or minimum control value.
With 16-bit protocol ±31457 bit. With 20-bit protocol ±503316 bit.
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #4
…
Bit #19
Unit with 16-bit protocol: In 10
–3
degrees.
Value range with 16-bit protocol: [0…65,535].
Unit with 20-bit protocol: In 10
–3
degrees.
Value range with 20-bit protocol: [0…65,535].
– Bit #0
…
Bit #3
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 24 As of scan system firmware  2001.
Aperture
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #4
…
Bit #19
Unit with 16-bit protocol: In mm.
Value range with 16-bit protocol: [0…65,535].
Unit with 20-bit protocol: In mm.
Value range with 20-bit protocol: [0…65,535].
– Bit #0
…
Bit #3
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
