RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
961
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 2B As of scan-system firmware  2060.
Flags from last stop event, lower 16 bits
16-bit
protocol
20-bit
protocol
–
Bit #0
…
Bit #15
Bit #0
…
Bit #19
–
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 2C As of scan-system firmware  2060.
Flags from last stop event, upper 16 bits
16-bit
protocol
20-bit
protocol
–
Bit #0
…
Bit #15
Bit #0
…
Bit #19
–
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
