20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
960
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 2A As of scan system firmware  2001.
Stop event code
Value range with 16-bit protocol: [0…65,535].
Value range with 20-bit protocol: [0…65,535].
16-bit
protocol
20-bit
protocol
(hex) (hex)
0001 00010 The galvanometer scanner has reached a critical edge
position.
0002 00020 AD converter error.
0003 00030 Temperature in scan system above max. allowed value.
0004 00040 External power supply voltages have dropped below the
allowed value.
0005 00050 Flags are not valid.
0006
…
000C
00060
…
000C0
Reserved.
…
Reserved.
000D 000D0 Reserved.
000E 000E0 Position Acknowledge time out (set position not reached for
long time).
000F 000F0 Reserved.
0014 00140 Reserved.
0015 00150 Reserved.
0016 00160 Reserved.
0017 00170 Reserved.
0018 00180 Reserved.
0019 00190 Reserved.
001A 001A0 Reserved.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
