20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
959
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 28 As of scan-system firmware  2060.
Diagnostic flags, lower 16 bits
16-bit
protocol
20-bit
protocol
–
Bit #0
…
Bit #15
Bit #0
…
Bit #19
–
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 29 As of scan-system firmware  2060.
Diagnostic flags, upper 16 bits
16-bit
protocol
20-bit
protocol
–
Bit #0
…
Bit #15
Bit #0
…
Bit #19
–
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
