Scanlab RTC6 PCIe Board - Page 958

RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
958
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 27 As of scan system firmware  2078.
Only after control_command ( Data = 17FF
H
): number of the temporarily stored data
type
16-bit
protocol
20-bit
protocol
Bit #8
…
Bit #15
Bit #12
…
Bit #19
= 0.
Bit #0
…
Bit #7
Bit #4
…
Bit #11
Cached setting.
– Bit #0
…
Bit #3
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
