20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
978
innovators for industry
Code
HIGH
(hex)
15 As of scan system firmware  2066.
SetPosAcknowledgeLevel
SetPosAcknowledgeLevel causes the scan system to switch to a certain PosAck limit value.
See also Chapter 8.1.6 ”Configuring the PosAck Limit Value”, page 222.
See also “On SetPosAcknowledgeLevel”, Seite 983.
Code
LOW
(hex)
00
…
FF
Desired PosAck limit value in LSB16, 16-bit protocol. In bits.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
17 As of scan system firmware  2078.
Store/RestoreTransmissionMode
Store/RestoreTransmissionMode causes with Code
LOW
= FF
H
the scan system to cache the
data type currently selected for transmission. It can be reinstated at a later time then with
Code
LOW
= 00
H
.
See also Data = 0527
H
.
See also “On Store/RestoreTransmissionMode”, Seite 983.
Code
LOW
(hex)
FF Store temporarily
00 Reinstate
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
