Siemens SINAMICS G120 - r0722.0...11 CO;BO: CU digital inputs status; CU DI status; r0722.0...12 CO;BO: CU digital inputs status; CU DI status; r0723.0...11 CO;BO: CU digital inputs status inverted; CU DI status inv

2 Parameters
2.2 List of parameters
SINAMICS G120 Control Units CU240B-2/CU240E-2
106 List Manual (LH11), 01/2016, A5E33839529
Description: Displays the status of the digital inputs.
Dependency: Refer to: r0723
Note: AI: Analog Input
DI: Digital Input
T: Terminal
Description: Displays the status of the digital inputs.
Dependency: Refer to: r0723
Note: AI: Analog Input
DI: Digital Input
T: Terminal
Description: Displays the inverted status of the digital inputs.
r0722.0...11 CO/BO: CU digital inputs status / CU DI status
CU240B-2
CU240B-2_DP
Access level: 2 Calculated: - Data type: Unsigned32
Can be changed: - Scaling: - Dyn. index: -
Unit group: - Unit selection: - Func. diagram: 2201, 2202, 2220,
2221, 2255, 2256, 2810
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 DI 0 (T. 5) High Low -
01 DI 1 (T. 6) High Low -
02 DI 2 (T. 7) High Low -
03 DI 3 (T. 8) High Low -
11 DI 11 (T. 3, 4) AI 0 High Low -
r0722.0...12 CO/BO: CU digital inputs status / CU DI status
CU240E-2
CU240E-2_DP
CU240E-2 PN
CU240E-2_F
CU240E-2_PN_F
CU240E-2_DP_F
Access level: 2 Calculated: - Data type: Unsigned32
Can be changed: - Scaling: - Dyn. index: -
Unit group: - Unit selection: - Func. diagram: 2201, 2202, 2220,
2221, 2255, 2256, 2810
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 DI 0 (T. 5) High Low -
01 DI 1 (T. 6) High Low -
02 DI 2 (T. 7) High Low -
03 DI 3 (T. 8) High Low -
04 DI 4 (T. 16) High Low -
05 DI 5 (T. 17) High Low -
11 DI 11 (T. 3, 4) AI 0 High Low -
12 DI 12 (T. 10, 11) AI 1 High Low -
r0723.0...11 CO/BO: CU digital inputs status inverted / CU DI status inv
CU240B-2
CU240B-2_DP
Access level: 3 Calculated: - Data type: Unsigned32
Can be changed: - Scaling: - Dyn. index: -
Unit group: - Unit selection: - Func. diagram: 2201, 2202, 2220,
2221, 2255, 2256
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 DI 0 (T. 5) High Low -
01 DI 1 (T. 6) High Low -
02 DI 2 (T. 7) High Low -
03 DI 3 (T. 8) High Low -
11 DI 11 (T. 3, 4) AI 0 High Low -
