3 Function diagrams
3.17 Free function blocks
Fig. 3-152 7240 – RSR 0 ... 2, DFR 0 ... 2
- 7240 -
Function diagram
87654321
fp_7240_97_61.vsd
Free function blocks - Flipflop function blocks
G120 CU240B/E-2
09.12.2015 V4.7.6
RSR 0 … 2, DFR 0 … 2
RSR 0
RSR 1
DFR 0
DFR 1
RSR 0 RTG
1 ... 9999
p20191 (9999)
RSR 0 RunSeq
0 ... 7999
p20192 (520)
RSR 0 output Q
r20189
[0]
RSR 0 inputs
p20188
[1] RSR 0 inv outp QN
r20190
DFR 0 RTG
1 ... 9999
p20201 (9999)
DFR 0 RunSeq
0 ... 32000
p20202 (550)
DFR 0 output Q
r20199
DFR 0 inv outp QN
r20200
[0]
DFR 0 inputs
p20198
[1]
[2]
[3]
RSR 1 RTG
1 ... 9999
p20196 (9999)
RSR 1 RunSeq
0 ... 7999
p20197 (530)
RSR 1 output Q
r20194
[0]
RSR 1 inputs
p20193
[1] RSR 1 inv outp QN
r20195
DFR 1 RTG
1 ... 9999
p20206 (9999)
DFR 1 RunSeq
0 ... 32000
p20207 (560)
DFR 1 output Q
r20204
DFR 1 inv outp QN
r20205
[0]
DFR 1 inputs
p20203
[1]
[2]
[3]
RSR 2 DFR 2
RSR 2 RTG
1 ... 9999
p20327 (9999)
RSR 2 RunSeq
0 ... 7999
p20328 (850)
RSR 2 output Q
r20325
[0]
RSR 2 inputs
p20324
[1] RSR 2 inv outp QN
r20326
DFR 2 RTG
1 ... 9999
p20332 (9999)
DFR 2 RunSeq
0 ... 32000
p20333 (870)
DFR 2 output Q
r20330
DFR 2 inv outp QN
r20331
[0]
DFR 2 inputs
p20329
[1]
[2]
[3]
Q
S
R
Set
Reset
QN
Q
S
R
Set
Reset
QN
Q
S
R
Set
Reset
QN
Q
S
D
Set
D input
QN
RReset
ITrigger input
Q
S
D
Set
D input
QN
RReset
ITrigger input
Q
S
D
Set
D input
QN
RReset
ITrigger input
RSR (RS flip-flop) DFR (D flip-flop)
