Siemens SINAMICS G120 - 3.6 Communication fieldbus interface (USS, Modbus)

SINAMICS G120 Control Units CU240B-2/CU240E-2
List Manual (LH11), 01/2016, A5E33839529
601
3 Function diagrams
3.6 Communication fieldbus interface (USS, Modbus)
3.6 Communication fieldbus interface (USS, Modbus)
Function diagrams
9310 – Configuration, addresses and diagnostics 602
9342 – STW1 control word interconnection 603
9352 – ZSW1 status word interconnection 604
9360 – Receive telegram, free interconnection via BICO (p0922 = 999) 605
9370 – Send telegram, free interconnection via BICO (p0922 = 999) 606
9372 – Status words, free interconnection 607
