Siemens SINAMICS G120 - Fig. 3-44 2505 - Control word, setpoint channel (r1198)

SINAMICS G120 Control Units CU240B-2/CU240E-2 List Manual (LH11), 01/2016, A5E33839529
611
3 Function diagrams
3.7 Internal control/status words
Fig. 3-44 2505 – Control word, setpoint channel (r1198)
- 2505 -
Function diagram
87654321
fp_2505_97_51.vsd
Internal control/status words
G120 CU240B/E-2
09.12.2015 V4.7.6
Control word, setpoint channel (r1198)
11
12
13
14
15
9
10
8
7
6
5
4
3
2
1
0
r1198.3
r1198.5
r1198.6
r1198.11
r1198.13
r1198.14
r1198.2
r1198.1
r1198.0
r1198.15
(0)
n_set_fixed Bit 0
p1020 [C]
(0)
n_set_fixed Bit 1
p1021 [C]
(0)
n_set_fixed Bit 2
p1022 [C]
(0)
n_set_fixed Bit 3
p1023 [C]
(2090.13)
Mop raise
p1035 [C]
(2090.14)
Mop lower
p1036 [C]
(0)
Bypass RFG
p1122 [C]
Control word setpoint channel (r1198)
1 = Fixed setpoint, bit 0
1 = Fixed setpoint, bit 1
1 = Fixed setpoint, bit 2
1 = Fixed setpoint, bit 3
Reserved
1 = Inhibit negative direction of rotation
1 = Inhibit positive direction of rotation
Reserved
Reserved
Reserved
Reserved
1 = Setpoint inversion
Reserved
1 = Motorized potentiometer, raise
1 = Motorized potentiometer, lower
1 = Bypass ramp-function generator
To fixed speed setpoints [3010.2], [3011.2]
To control word 2 [2513.2]
To fixed speed setpoints [3010.2], [3011.2]
To control word 2 [2513.2]
To fixed speed setpoints [3010.2], [3011.2]
To control word 2 [2513.2]
To fixed speed setpoints [3010.2], [3011.2]
To control word 2 [2513.2]
To direction of rotation limiting and
direction of rotation reversal [3040.3]
To direction of rotation limiting and
direction of rotation reversal [3040.5]
To direction of rotation limiting and
direction of rotation reversal [3040.2]
To the motorized potentiometer [3020.1]
To the motorized potentiometer [3020.1]
To the ramp-function generator [3060.1], [3070.1]
STW setpoint chan
r1198
r1198
Bit No.
(0)
Inhib neg dir
p1110 [C]
(0)
Inhib pos dir
p1111 [C]
(2090.11)
Setp inv
p1113 [C]
To control word 1 [2512.4]
To control word 1 [2512.4]
