Advanced-control timers (TIM1/TIM8/TIM20) RM0440
1222/2126 RM0440 Rev 4
Note: Refer to Section 28.3.2: TIM1/TIM8/TIM20 pins and internal signals for product specific
implementation.
28.6.29 TIMx DMA control register (TIMx_DCR)(x = 1, 8, 20)
Address offset: 0x3DC
Reset value: 0x0000 0000
Bit 3 BK2CMP3E: tim_brk2_cmp3 enable
This bit enables the tim_brk2_cmp3 for the timer’s tim_brk2 input. tim_brk2_cmp3 output is
‘ORed’ with the other tim_brk2 sources.
0: tim_brk2_cmp3 input disabled
1: tim_brk2_cmp3 input enabled
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
Bit 2 BK2CMP2E: tim_brk2_cmp2 enable
This bit enables the tim_brk2_cmp2 for the timer’s tim_brk2 input. tim_brk2_cmp2 output is
‘ORed’ with the other tim_brk2 sources.
0: tim_brk2_cmp2 input disabled
1: tim_brk2_cmp2 input enabled
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
Bit 1 BK2CMP1E: tim_brk2_cmp1 enable
This bit enables the tim_brk2_cmp1 for the timer’s tim_brk2 input. tim_brk2_cmp1 output is
‘ORed’ with the other tim_brk2 sources.
0: tim_brk2_cmp1 input disabled
1: tim_brk2_cmp1 input enabled
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
Bit 0 BK2INE: TIMx_BKIN2 input enable
This bit enables the TIMx_BKIN2 alternate function input for the timer’s tim_brk2 input.
TIMx_BKIN2 input is ‘ORed’ with the other tim_brk2 sources.
0: TIMx_BKIN2 input disabled
1: TIMx_BKIN2 input enabled
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. DBL[4:0] Res. Res. Res. DBA[4:0]
rw rw rw rw rw rw rw rw rw rw
