Page #685 background image
RM0440 Rev 4 685/2126
RM0440 Analog-to-digital converters (ADC)
724
By replacing V
REF+
by the formula provided above, the absolute voltage value is given by
the following formula
For applications where V
DDA
is known and ADC converted values are right-aligned, the
absolute voltage value can be obtained by using the following formula:
Where:
–V
DDA_Charac
is the value of V
DDA
voltage characterized at V
REFINT
during the
manufacturing process.
VREFINT_CAL is the V
REFINT
calibration value
ADC_DATA is the value measured by the ADC on channel x (right-aligned)
VREFINT_DATA is the actual V
REFINT
output value converted by the ADC
FULL_SCALE is the maximum digital value of the ADC output. For example with
12-bit resolution, it will be 2
12
- 1 = 4095 or with 8-bit resolution, 2
8
- 1 = 255.
Note: If ADC measurements are done using an output format other than 16-bit right-aligned, all
the parameters must first be converted to a compatible format before the calculation is
done.
21.5 ADC interrupts
For each ADC, an interrupt can be generated:
After ADC power-up, when the ADC is ready (flag ADRDY)
On the end of any conversion for regular groups (flag EOC)
On the end of a sequence of conversion for regular groups (flag EOS)
On the end of any conversion for injected groups (flag JEOC)
On the end of a sequence of conversion for injected groups (flag JEOS)
When an analog watchdog detection occurs (flag AWD1, AWD2 and AWD3)
When the end of sampling phase occurs (flag EOSMP)
When the data overrun occurs (flag OVR)
When the injected sequence context queue overflows (flag JQOVF)
Separate interrupt enable bits are available for flexibility.
V
CHANNELx
V
DDA_Charac
VREFINT_CAL ADC_DATA××
VREFINT_DATA FULL_SCALE×
---------------------------------------------------------------------------------------------------------------------
=
V
CHANNELx
V
DDA
FULL_SCALE
-------------------------------------
ADC_DATA×=
Table 174. ADC interrupts per each ADC
Interrupt event Event flag Enable control bit
ADC ready ADRDY ADRDYIE
End of conversion of a regular group EOC EOCIE
End of sequence of conversions of a regular group EOS EOSIE
End of conversion of a injected group JEOC JEOCIE
