Analog-to-digital converters (ADC) RM0440
662/2126 RM0440 Rev 4
Figure 130. 20-bit to 16-bit result truncation
Figure 131 gives a numerical example of the processing, from a raw 20-bit accumulated
data to the final 16-bit result.
Figure 131. Numerical example with 5-bit shift and rounding
Table 172 gives the data format for the various N and M combinations, for a raw conversion
data equal to 0xFFF.
There are no changes for conversion timings in oversampled mode: the sample time is
maintained equal during the whole oversampling sequence. A new data is provided every N
MS34453V1
Raw 20-bit data
19 15 11 7 3 0
Shifting
15 0
Truncation and rounding
MS34454V1
7D73Raw 20-bit data
19 15 11 7 3
0
FBD1
Final result after 5-bit shift
and rounding to nearest
B
15
Table 172. Maximum output results versus N and M (gray cells indicate truncation)
Over
sampling
ratio
Max
Raw data
No-shift
OVSS =
0000
1-bit
shift
OVSS =
0001
2-bit
shift
OVSS =
0010
3-bit
shift
OVSS =
0011
4-bit
shift
OVSS =
0100
5-bit
shift
OVSS =
0101
6-bit
shift
OVSS =
0110
7-bit
shift
OVSS =
0111
8-bit
shift
OVSS =
1000
2x 0x1FFE 0x1FFE 0x0FFF 0x0800 0x0400 0x0200 0x0100 0x0080 0x0040 0x020
4x 0x3FFC 0x3FFC 0x1FFE 0x0FFF 0x0800 0x0400 0x0200 0x0100 0x0080 0x0040
8x 0x7FF8 0x7FF8 0x3FFC 0x1FFE 0x0FFF 0x0800 0x0400 0x0200 0x0100 0x0080
16x 0xFFF0 0xFFF0 0x7FF8 0x3FFC 0x1FFE 0x0FFF 0x0800 0x0400 0x0200 0x0100
32x 0x1FFE0
0xFFE0 0xFFF0 0x7FF8 0x3FFC 0x1FFE 0x0FFF 0x0800 0x0400 0x0200
64x 0x3FFC0
0xFFC0 0xFFE0 0xFFF0 0x7FF8 0x3FFC 0x1FFE 0x0FFF 0x0800 0x0400
128x 0x7FF80
0xFF80 0xFFC0 0xFFE0 0xFFF0 0x7FF8 0x3FFC 0x1FFE 0x0FFF 0x0800
256x 0xFFF00
0xFF00 0xFF80 0xFFC0 0xFFE0 0xFFF0 0x7FF8 0x3FFC 0x1FFE 0x0FFF
