RM0440 Rev 4 1349/2126
RM0440 General-purpose timers (TIM15/TIM16/TIM17)
1445
Table 290 lists the internal sources connected to the tim_itr input multiplexer.
tim_ti1_in4 comp5_out RTC Clock RTC Clock
tim_ti1_in5 comp7_out LSE LSE
tim_ti1_in6 Reserved LSI LSI
tim_ti1_in[7..15] Reserved
1. This signal is available only if the HSE32EN bit is set in the TIMx_OR1 register. See
Section 30.8.15: TIMx option register 1 (TIMx_OR1)(x = 16 to 17) for details.
Table 289. Interconnect to the tim_ti2 input multiplexer
tim_ti2 inputs
Sources
TIM15
tim_ti2_in0 TIM15_CH2
tim_ti2_in1 comp2_out
tim_ti2_in2 comp3_out
tim_ti2_in3 comp6_out
tim_ti2_in4 comp7_out
tim_ti2_in[5..15] Reserved
Table 290. TIMx internal trigger connection
tim_itrx inputs TIM15
tim_itr0
tim1_trgo
tim_itr1
tim2_trgo
tim_itr2
tim3_trgo
tim_itr3
tim4_trgo
tim_itr4
tim5_trgo
tim_itr5
tim8_trgo
tim_itr6
Reserved
tim_itr7
tim16_oc1
tim_itr8
tim17_oc1
tim_itr9
tim20_trgo
tim_itr10
hrtim_out_sync2
tim_itr11..15
Reserved
Table 288. Interconnect to the tim_ti1 input multiplexer (continued)
tim_ti1 inputs
Sources
TIM15 TIM16 TIM17
