It order to function correctly with the RCC, the clock request signal is activated (conditional
on WUPEN) when there is asynchronous activity on:
• Type-C voltage threshold detectors (coming from either CC line)
• Power Delivery receiver signal (from the selected CC line)
• FRS detection signal (from the selected CC line)
46.6 UCPD interrupts
The table below lists the UCPD event flags, with the associated flag clear bits and interrupt
enable bits.
When an interrupt from the UCPD is received, then the software has to check what is the
source of the interrupt by reading the UCPD_SR register.
Depending on which bit is at 1, the ISR must handle that condition and clear the bit by a
write to the appropriate bit of the UCPD_ICR register.
46.7 UCPD registers
46.7.1 UCPD configuration register 1 (UCPD_CFGR1)
Address offset: 0x000
Table 428. UCPD interrupt requests
Interrupt event Event flag
Event flag/Interrupt
clearing method
Interrupt enable
control bit
FRS detection FRSEVT Set FRSEVTCF FRSEVTIE
Type C voltage level change on CC2 TYPECEVT2 Set TYPECEVT2CF TYPECEVT2IE
Type C voltage level change on CC1 TYPECEVT1 Set TYPECEVT1CF TYPECEVT1IE
Rx message received RXMSGEND Set RXMSGENDCF RXMSGENDIE
Rx data overflow RXOVR Set RXOVRCF RXOVR
Rx Hard Reset detected RXHRSTDET Set RXHRSTDETCF RXHRSTDETIE
Rx ordered set (4 K-codes) detected RXORDDET Set RXORDDETCF RXORDDETIE
Receive data register not empty RXNE
Read data in
UCPD_RXDR
RXNEIE
Tx data underrun TXUND Set TXUNDCF TXUNDIE
Hard Reset sent HRSTSENT Set HRSTSENTCF HRSTSENTIE
Hard Reset discarded HRSTDISC Set HRSTDISCCF HRSTDISCIE
Transmit message aborted TXMSGABT Set TXMSGABTCF TXMSGABTIE
Transmit message sent TXMSGSENT Set TXMSGSENTCF TXMSGSENTIE
Transmit message discarded TXMSGDISC Set TXMSGDISCCF TXMSGDISCIE
Transmit data required TXIS
Write data to the
UCPD_TXDR register
TXISIE
