Flexible static memor
y controller (FSMC)
RM0440
544/2126
RM0440 Rev 4
The
FMC supports
both
NOR Flash
wait state
configurations, fo
r
each chip
select,
thanks to
the W
AITCFG
bit in the FMC_BCRx registers (x = 0..3).
Figure 69. W
ait configuration waveforms
addr[15:0]
data
data
addr[25:16]
Memory transaction = burst of 4 half words
HCLK
CLK
A[25:16]
NADV
NW
AIT
(W
AITCFG = 1)
A/D[15:0]
inserted wait state
data
NW
AIT
(W
AITCFG = 0)
ai15798c
543
545
