RM0440 Rev 4 1231/2126
RM0440 General-purpose timers (TIM2/TIM3/TIM4/TIM5)
1343
Table 270, Table 271, Table 272 and Table 273 are listing the sources connected to the
tim_ti[1..4] input multiplexers.
tim_ker_ck Input
Timer kernel clock. This clock must be
synchronous with tim_pclk (derived from the
same source). The clock ratio
tim_ker_ck/tim_pclk must be an integer:1, 2,
3,..., 8 (maximum value).
tim_it Output
Global Timer interrupt, gathering
capture/compare, update, break trigger and
commutation requests.
tim_cc1_dma
tim_cc2_dma
tim_cc3_dma
tim_cc4_dma
Output Timer capture / compare 1..4 dma requests.
tim_upd_dma Output Timer update dma request.
tim_trg_dma Output Timer trigger dma request.
tim_com_dma Output Timer commutation dma request.
Table 270. Interconnect to the tim_ti1 input multiplexer
tim_ti1 inputs
Sources
TIM2 TIM3 TIM4 TIM5
tim_ti1_in0 TIM2_CH1 TIM3_CH1 TIM4_CH1 TIM5_CH1
tim_ti1_in1 comp1_out comp1_out comp1_out LSI
tim_ti1_in2 comp2_out comp2_out comp2_out LSE
tim_ti1_in3 comp3_out comp3_out comp3_out RTC wake-up
tim_ti1_in4 comp4_out comp4_out comp4_out comp1_out
tim_ti1_in5 comp5_out comp5_out comp5_out comp2_out
tim_ti1_in6
Reserved
comp6_out comp6_out comp3_out
tim_ti1_in7 comp7_out comp7_out comp4_out
tim_ti1_in8
Reserved Reserved
comp5_out
tim_ti1_in9 comp6_out
tim_ti1_in10 comp7_out
tim_ti1_in[11..15] Reserved
Table 269. TIM internal input/output signals (continued)
Internal signal name Signal type Description
