Embedded Flash memory (FLASH) for cat
egory 4 devices
RM0440
172/2126
RM0440 Rev 4
4.6
FLASH interrupts
T
able 26. Flash interrupt request
Interrupt event
Event flag
Event flag/interrupt
clearing method
Interrupt enable co
n
trol
bit
End of operation
EOP
(1)
1.
EOP is set only if EOPIE is set.
Write EOP=1
EOPIE
Operation error
OPERR
(2)
2.
OPERR is set only if ERRIE is set.
Write OPERR=1
ERRIE
Read error
RDERR
Write RDERR=1
RDERRIE
ECC correction
ECCC
Write ECCC=1
ECCCIE
