Analog-to-digital converters (ADC) RM0440

628/2126 RM0440 Rev 4

adc_ext_trg9 TIM1_TRGO Internal signal from on-chip timers 01001

adc_ext_trg10 TIM1_TRGO2 Internal signal from on-chip timers 01010

adc_ext_trg11 TIM2_TRGO Internal signal from on-chip timers 01011

adc_ext_trg12 TIM4_TRGO Internal signal from on-chip timers 01100

adc_ext_trg13 TIM6_TRGO Internal signal from on-chip timers 01101

adc_ext_trg14 TIM15_TRGO Internal signal from on-chip timers 01110

adc_ext_trg15 TIM3_CC4 Internal signal from on-chip timers 01111

adc_ext_trg16 TIM20_TRGO Internal signal from on-chip timers 10000

adc_ext_trg17 TIM20_TRGO2 Internal signal from on-chip timers 10001

adc_ext_trg18 TIM20_CC1 Internal signal from on-chip timers 10010

adc_ext_trg19 TIM20_CC2 Internal signal from on-chip timers 10011

adc_ext_trg20 TIM20_CC3 Internal signal from on-chip timers 10100

adc_ext_trg21 hrtim_adc_trg1 Internal signal from on-chip timers 10101

adc_ext_trg22 hrtim_adc_trg3 Internal signal from on-chip timers 10110

adc_ext_trg23 hrtim_adc_trg5 Internal signal from on-chip timers 10111

adc_ext_trg24 hrtim_adc_trg6 Internal signal from on-chip timers 11000

adc_ext_trg25 hrtim_adc_trg7 Internal signal from on-chip timers 11001

adc_ext_trg26 hrtim_adc_trg8 Internal signal from on-chip timers 11010

adc_ext_trg27 hrtim_adc_trg9 Internal signal from on-chip timers 11011

adc_ext_trg28 hrtim_adc_trg10 Internal signal from on-chip timers 11100

adc_ext_trg29 LPTIMOUT Internal signal from on-chip timers 11101

adc_ext_trg30 TIM7_TRGO Internal signal from on-chip timers 11110

adc_ext_trg31 reserved - 11111

Table 163. ADC1/2 - External triggers for regular channels (continued)

Name Source Type EXTSEL[4:0]

Table 164. ADC1/2 - External trigger for injected channels

Name Source Type JEXTSEL[4:0]

adc_jext_trg0 TIM1_TRGO Internal signal from on-chip timers 00000

adc_jext_trg1 TIM1_CC4 Internal signal from on-chip timers 00001

adc_jext_trg2 TIM2_TRGO Internal signal from on-chip timers 00010

adc_jext_trg3 TIM2_CC1 Internal signal from on-chip timers 00011

adc_jext_trg4 TIM3_CC4 Internal signal from on-chip timers 00100

adc_jext_trg5 TIM4_TRGO Internal signal from on-chip timers 00101

adc_jext_trg6 EXTI line 15 External pin 00110

adc_jext_trg7 TIM8_CC4 Internal signal from on-chip timers 00111

adc_jext_trg8 TIM1_TRGO2 Internal signal from on-chip timers 01000
