ST STM32G471 User Manual

RM0440 Rev 4 2069/2126
RM0440 USB Type-C™ / USB Power Delivery interface (UCPD)
2079
46.7.5 UCPD status register (UCPD_SR)
Address offset: 0x014
Reset value: 0x0000 0000
The flags (single-bit status bitfields) are associated with interrupt request. Interrupt is
generated if enabled by the corresponding bit of the UCPD_IMR register.
Bit 4 HRSTDISCIE: HRSTDISC interrupt enable
0: Disable
1: Enable
Bit 3 TXMSGABTIE: TXMSGABT interrupt enable
0: Disable
1: Enable
Bit 2 TXMSGSENTIE: TXMSGSENT interrupt enable
0: Disable
1: Enable
Bit 1 TXMSGDISCIE: TXMSGDISC interrupt enable
0: Disable
1: Enable
Bit 0 TXISIE: TXIS interrupt enable
0: Disable
1: Enable
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
FRSEVT
TYPEC_VSTATE_CC2[1:0] TYPEC_VSTATE_CC1[1:0]
rrrrr
1514131211109876543210
TYPECEVT2 TYPECEVT1
RXERR
RXMSGEND
RXOVR
RXHRSTDET
RXORDDET
RXNE Res.
TXUND
HRSTSENT
HRSTDISC
TXMSGABT
TXMSGSENT
TXMSGDISC
TXIS
rrrrrrrr rrrrrrr
