RM0440 Digital-to-analog converter (DAC)
773
22.7.6 DAC channel2 12-bit right aligned data holding register
(DAC_DHR12R2)
This register is available only on dual-channel DACs. Refer to Section 22.3: DAC
implementation.
Address offset: 0x14
Reset value: 0x0000 0000
22.7.7 DAC channel2 12-bit left aligned data holding register
(DAC_DHR12L2)
This register is available only on dual-channel DACs. Refer to Section 22.3: DAC
implementation.
Address offset: 0x18
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. DACC2DHRB[11:0]
rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
Res. Res. Res. Res. DACC2DHR[11:0]
rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:28 Reserved, must be kept at reset value.
Bits 27:16 DACC2DHRB[11:0]: DAC channel2 12-bit right-aligned data
These bits are written by software. They specify 12-bit data for DAC channel2 when the DAC
operates in DMA Double data mode.
Bits 15:12 Reserved, must be kept at reset value.
Bits 11:0 DACC2DHR[11:0]: DAC channel2 12-bit right-aligned data
These bits are written by software. They specify 12-bit data for DAC channel2.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
DACC2DHRB[11:0] Res. Res. Res. Res.
rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
DACC2DHR[11:0] Res. Res. Res. Res.
rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:20 DACC2DHRB[11:0]: DAC channel2 12-bit left-aligned data B
These bits are written by software. They specify 12-bit data for DAC channel2 when the
DAC operates in Double data mode.
Bits 19:16 Reserved, must be kept at reset value.
Bits 15:4 DACC2DHR[11:0]: DAC channel2 12-bit left-aligned data
These bits are written by software which specify 12-bit data for DAC channel2.
Bits 3:0 Reserved, must be kept at reset value.
