Hard disk drives / solid state drives
SAS cabling with one SAS 3.0 controller and one SAS 2.0 controller
SAS cabling with one SAS 2.0 controller and SAS expander board
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
SAS 3.0 cable
Y4040-V8
27
Connector MLC 1 on
SAS 3.0 controller 1
in PCI slot 10
SAS 3.0 backplane 1
connector X5
16.2.16
SAS 3.0 cable
Y4040-V8
27
Connector MLC 2 on
SAS 3.0 controller 1
in PCI slot 10
SAS 3.0 backplane 2
connector X5
SAS 2.0 cable
Y3963-V107
18
Connector MLC 1 on
SAS 2.0 controller 2
in PCI slot 3
SAS 2.0 backplane 3
connector X1
16.2.16
SAS 2.0 cable
Y3963-V107
18
Connector MLC 2 on
SAS 2.0 controller 2
in PCI slot 3
SAS 2.0 backplane 4
connector X1
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
SAS 2.0 cable
Y3963-V112
15
Connector X1 on
SAS expander board
SAS 2.0 backplane 1
connector X1
16.2.17
SAS 2.0 cable
Y3963-V112
15
Connector X2 on
SAS expander board
SAS 2.0 backplane 2
connector X1
SAS 2.0 cable
Y3963-V151/V101
16
Connector X3 on
SAS expander board
SAS 2.0 backplane 3
connector X1
SAS 2.0 cable
Y3963-V151/V101
16
Connector X4 on
SAS expander board
SAS 2.0 backplane 4
connector X1
SAS 2.0 cable
Y3963-V151/V101
16
Connector MLC 1 on
SAS 2.0 controller 1
in PCI slot 10
Connector MLC 1 on
SAS expander board
16.2.17
SAS 2.0 cable
Y3963-V151/V101
16
Connector MLC 2 on
SAS 2.0 controller 1
in PCI slot 10
Connector MLC 2 on
SAS expander board
