Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 195
Hard disk drives / solid state drives
Power cabling
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
HDD power cable
Y3952-V601
1
Power backplane
connector X21
SAS backplane 1
connector
X6 (SAS 2.0) /
X10 (SAS 3.0)
(HDDs 1, 5, 9, 13)
Cable connector P2
16.2.12
SAS backplane 2
connector
X6 (SAS 2.0) /
X10 (SAS 3.0)
(HDDs 2, 6, 10, 14)
Cable connector P1
SAS backplane 3
connector
X6 (SAS 2.0) /
X10 (SAS 3.0)
(HDDs 3, 7, 11, 15)
Cable connector P4
SAS backplane 4
connector
X6 (SAS 2.0) /
X10 (SAS 3.0)
(HDDs 4, 8, 12, 16)
Cable connector P3
