Fujitsu PRIMERGY RX350 S8

386 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Expansion cards and backup units
Ê Connect the GPGPU power cables to the power backplane:
Additional power cabling for high performance coprocessor cards
I This description applies only to high performance coprocessor cards
Intel Xeon Phi 3120P / 31S1P / 7120P.
Figure 267: HDD / GPGPU / coprocessor card power cable (T26139-Y3952-V701)
# Connector Cable
1 X22
GPGPU / coprocessor card power cable
T26139-Y3946-V701
2 X23
