Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 711
Converting a tower server to a rack server
Figure 554: Removing the right side cover (B)
Ê Slide the right side cover towards the server rear as far as it will go.
Ê Ensure that the three hooks on the right side cover rest in the wide ends of
the slots on the upper chassis edge (see close-up).
