Pos. Component Reference
1
3.5-inch hard disk drives /
dummy modules
"3.5-inch HDD configurations" on
page 241
2
Local service display
module (LSD)
"Accessible drive bays" on page 530
3ID card "Opening the server" on page 68
4
2x 3.5-inch HDD
extension box with LSD
and slimline ODD bays
"HDD extension boxes" on page 284
5 Optical disk drive
"Accessible drive bays" on page 530
6
Backup drive /
5.25-inch dummy module
7
Front panel module:
2 USB connectors
"Replacing the front panel module" on
page 601
8
Front panel module:
Front Management LAN
connector (optional)
"Replacing the front LAN connector and
board" on page 630
9
Front panel module:
Front VGA connector
(optional)
"Replacing the front VGA connector" on
page 641
