Inficon HAPSITE Smart - 5.6 GC;MS Mode with Headspace Sampling System and Sample Loop Installed

5 - 32
IPN 074-397-P1G
HAPSITE Smart Operating Manual
5.6 GC/MS Mode with Headspace Sampling System and Sample
Loop Installed
The Headspace Sampling System is used to test liquid and soil samples. Refer to
Chapter 13, Headspace Sampling System for more information on the Headspace
System. Refer to Section 2.6, Headspace Sampling System, on page 2-12 for
assembly instructions. Refer to Chapter 6, Methods for additional information on
GC/MS methods.
1 Double-click the Smart IQ icon.
2 Double-click on the Run Method icon.
3 Double-click the GCMS folder. SeeFigure 5-47.
Figure 5-47 Choosing the Mode of Operation
