7.5.1 Tool Bar
Figure 7-17 Manual Tune Tool Bar
Filament On/Off. . . . . . . . . . Turns the emission On or Off.
Multiplier On/Off . . . . . . . . . Turns the Electron Multiplier On or Off.
Full Scan . . . . . . . . . . . . . . . Switches between Full Scan display mode
and Peak Scan display mode.
Zoom . . . . . . . . . . . . . . . . . . Enables the cursor to select a section of Full
Scan or Peak Scan and zoom to that section.
Mass Adjust . . . . . . . . . . . . Enables the cursor to select a mass peak
and drag the mass peak to a different
position on the mass axis.
Short Autotune . . . . . . . . . . Starts the Short Autotune function.
Long Autotune . . . . . . . . . . Starts the Long Autotune function.
Mass Calibration. . . . . . . . . Checks and corrects the ten calibration
masses for correct location within the mass
range.
Noise Check . . . . . . . . . . . . Scans a "quiet" mass range (no peaks) to
determine the electronic baseline and
threshold noise level.
Perform Tune Checkup . . . Runs a mass calibration and noise check.
Show Target . . . . . . . . . . . . Displays the target bar for the mass peak
center and peak width at 10% peak height.
Displays the target high and low percentage
bars for each mass peak.
