10 - 4
IPN 074-397-P1G
HAPSITE Smart Operating Manual
The system allows flexibility to add Date or Date and Time as a prefix or suffix, or
use a different naming convention if Use Default Filename is not selected.
10.1.4 Tune Files
If Tune is performed automatically (Autotune as part of normal operation), then the
file name is specified as part of the Method file. Also, the updated Tune is saved
automatically under the name specified in the Method file. Refer to Chapter 7, Tune
for additional information on Tune.
NOTE: Manual Tuning requires Advanced access. Normal users do not have
access to Manual Tune. Refer to section 8.10, Access Levels, on page
8-34 for additional information on Access Levels.
If Manual Tune is performed, the file must be saved to the Tune folder on the
HAPSITE. Figure 10-5 shows a typical Manual Tune screen, which is opened by
selecting the Tune icon in System Setup, or by right clicking on a sensor icon and
selecting Tune. To save changes made during manual tuning, press the Save Tune
button on the Function toolbar and tune will be saved immediately. Other ways to
save a tune file include using File >> Save, File >> Save As, or Tune >> Save
Tune Parameters.
NOTE: Tune files are saved, by default, to the HAPSITE hard drive under the
\Tune folder.
Figure 10-5 Manual Tuning Screen Showing Save Tune Button
