7 - 25
IPN 074-397-P1G
HAPSITE Smart Operating Manual
NOTE: The menu from the control panel is the same as above with the exception
of no print function.
Print... . . . . . . . . . . . . . . . . . . . . . . . Prints the Tune Status panel or the Mass
Calibration Status panel.
Show Tune Status Panel . . . . . . . . Displays the Tune Status panel.
Show Mass Calibration Status . . . . . . . . Displays the Mass Calibration
Status panel.
Tile Grids Horizontally . . . . . . . . . . Tiles the Status and Calibration Status panels
horizontally.
Tile Grids Vertically . . . . . . . . . . . . Tiles the Status and Calibration Status panels
vertically.
Size Columns To Grid . . . . . . . . . . Resets the column size to the current grid.
Dock. . . . . . . . . . . . . . . . . . . . . . . . . Locks the display position to a fixed position.
Properties.... . . . . . . . . . . . . . . . . . . Displays the Properties window.
7.5.8.3 RMB on Y Axis
Positioning the mouse cursor on the Y axis scale near the top and selecting the
right mouse button will bring up a Y axis scale scroll window.
7.6 Performing Manual Tune
Manual tune is a procedure that should only be attempted
by experienced HAPSITE users who preferably have
taken the Advanced Training course provided by
INFICON.
Read section 7.5, Manual Tune Settings and Controls, on page 7-9 to learn about
the various controls and settings involved in manual tune. Remember when
attempting a manual tune, if after a few cycles through the manual tune process
the HAPSITE is still not tuning, call INFICON Support for additional guidance.
Below are general guidelines for performing a manual tune.
NOTE: Do not save a Tune file from a Manual Tune if it indicates the HAPSITE is
not tuned.
